46 Installation—Installing the FC-2000
DC AM PS
0 1 2 3
DC VO LTS
0 15 20 25 30 35
P7
Step 1
Step 2
Step 3
mpminstl
P7
MPS-24A
MPS-24A
MPM-2
MPS-24A
MPM-2
Figure 33: Installing an Optional Main Power Meter
