Installation—Installing the FC-2000 49
Figure 35: Harness Connections for the MPS-24B
Harness
Connections for
the MPS-24B
J5 J6
MPS-24B
Power Ribbon
(71085)
Power Harness
(71086)
Connect to P2.
CPU
(bottom view)
7-position end
MPS-24B Bell Power
Harness
(71093)
Connect to
J5 on the CPU
Blue Wire (+)
Black Wire (-)
Note position of
red wire at
8-position end.
Connector Orientation
P3
P2
P4
JP3
TB1
P5
TB2
JP1
mps24bwr
1 2 3 4 5 6
1 2 3 4 5
