76 Installation—Installing the FC-2000
A total of 3.0 amps (internal) @ 24 VDC regulated is available from the
MPS-24A Main Power Supply during standby. No more than 6 amps
@ 24 VDC can be drawn from the MPS-24A during alarm. The MPS-24B
provides 750 mA of regulated power for system modules and 2.0 amps for
indicating appliances.
Table 2: Primary Power Standby Current Requirements
Device Type Number of
Devices
Multiply
By
Current
in Amps
Total
Current/Device
CPU
1 X 0.031 0.031
MPS-24A
1 X 0.064 0.064
MPS-24B
1 X 0.062 0.062
AVPS-24
[ ] X 0.009
EFB-1
[ ] X 0.011
MPM-2
[ ] X 0.006
IZM-8
[ ] X 0.047
IZE-A
[ ] X 0.004
ICM-4, CRM-4
[ ] X 0.007
ICE-4, VCE-4
[ ] X 0.001
CRE-4
[] X 0
TCM-2, TCM-4,
VCM-4
[ ] X 0.007
DCM-4
[ ] X 0.008
AIM-200
Use the standby draw from the
AIM-200
Addressable Intelligent Module
Technical Bulletin
in this manual
Annunciator Modules (LEDs Off)
ACM-16AT,
ACM-32A,
[ ] X 0.040
AEM-16AT,
AEM-32A
[ ] X 0.002
LCD-80 [ ] X 0.100
ACM-8R
Annunciator
Control
Module
Use the Standby Total from the
ACM-8R
Annunciator Control Module Technical Bulletin
in
the
Fire Management Accessories Manual
(FAN 445)
LDM Series
Annunciators
Use the Standby Total from the
LDM Lamp
Driver Modules
Technical Bulletin
in the
Fire
Management Accessories Manual
(FAN 445)
Annunciator Modules (Additional LED current for Annunciator LEDs illuminated
during non-alarm conditions)
ACM-16,
ACM-32,
AEM-16AT,
AEM-32A
[ ] X 0.016
NIB-96
[ ] X 0.022
Continued on next page . . .
