Joyner TROOPER-T2 - Case&Accessory

168
1 CASE&ACCESSORY
Ref
ERP code
Part No. Part Description Qty
11
02.DLJ.5T07－1701001 5T07－1701001
Locating pin 2
12
02.DLJ.5T07－1701002 5T07－1701002
Oil plug screw 1
13
02.DLJ.5T07－1701003 5T07－1701003
Screw plug washer 2
14
02.DLJ.5T07－3729010 5T07－3729010
Back－up light switch
1
15
02.DLJ.5T0－1701058A 5T07－1701058A
Double－screw rod
1
16
02.DLJ.5T07－1701009 5T07－1701009
Bearing stop plate 1
17
02.DLJ.5T07－1701004 5T07－1701004
Oil－stop plate
1
18
03.01.5787-M6×12/05
5787－AM6X12
Flange bolt M6x12 2
19
03.02.2842-M6/05
7246－W6
Flat washer 6 4
20
02.DLJ.5T07－1701400 5T07－1701400
Oil groove 1
21
02.TR1100.04.01.02.01
TR1100.04.01.02.01 Clutch rocker 1
22
03.01.5787-M8×35/05
5787－AM8X35
Flange bolt M8x35 1
23
03.02.2842-M8/05
6177.1－8
Flange nut M8 1
24
02.DLJ.5T07－1701603 5T07－1701603
Side cover bolt 8
25
02.DLJ.QR51－1602113 QR512－1602113
Declutch release spring 1
26 02.S800.04.01.02.
S800.04.01.02.0－R2
512 Transmission assy 1
