60
Rear fuses and relays box
Bulb replacement
To replace the bulb of the head light:
1. Loose the 2 crews at the bottom of the head light, and take off the 2 hoops around
the head light.
2. Separate the head light as the picture.
3. Unscrew the screw that fixes the bulb, and take off the bulb carefully.
4. Disconnect the bulb from the wiring.
5. Connect a new bulb with the same specification to the wiring.
6. Put all the parts disassembled above with reversing step 1～4.
Engine relay
Fuel pump relay
Fan relay
ECU normal open circuits fuse
Gauge and indicator fuse
EFI fuse
ECU normal close circuits fuse
Fuel pump fuse
Engine fuse
Fan fuse
