62
To replace the bulb of the taillight:
1. Unscrew the 6 screws from the taillight.
2. Separate the taillight cover from the taillight body.
3. Take off the bulb you need to replace through turning the bulb counter clockwise
about a half round, and replace a new one.
4. Put all the parts back with reversing step 1～2.
Shock adjustment
After a long time use, the shock need to be adjusted for more tension refer to
maintenance and service log, adjust the shock with a special spanner. In other case, the
chock nitrogen needs to be added to get more nitrogen pressure; the recommended
nitrogen pressure is 1.0MPa/145psi.
Adjust the shock refer to the following drawing.
Screw
Tailli
