63
set up
set up
S(mm)
P(N)
40 0
50
6793
Front shock spring specification
115
1563
3518
S(mm)
P(N)
35 0
11299
155
2551
Rear shock spring specification
1. Loose the lock nut on the top of the shock spring, and then turn the pushing-nut
clockwise to increase tension, and counter clockwise to decrease tension.
Lock nut Pushing nut
Special spanner
Clock wise
Special spanner
