Joyner TROOPER-T2 - Fuel Tank; Seats and Safety Belts

34
Never use 4DW with both front differentials locked and rear differential locked at a high
speed, because the work mode of 4DW with both front differentials locked and rear
differential locked will make the steering hard.
Fuel tank
Fuel tank locate under the passenger seat, and
fuel tank cap locate behind the passenger seat.
unlock Seat lock and turn passenger Seat over
before unscrew fuel tank cap.
add gasoline to about 80% of fuel tank.
z Never overfill the gas tank.
z Keep the fuel tank cap clean.
z Make sure to cover the key hole back
after use
z to prevent dirt from entering the lock mechanism
Seats and safety belts
Seats
To slide the seat back and forwards on the Trooper, pull the lever located in the front of
the seat upward, hold the lever in that position and adjust the seat to the desired position.
Be sure the adjustment lever is back on its full lock position and the seat is locked in
place.
1. Pull seat lock lever under left leg upward.
2. Move the Seats backwards or forwards
as your need.
3. Release the lock lever, so the Seat is locked
in the position you want.
To access the battery compartment the
compartment is located underneath the passenger
seat the seat can be lifted in the same manner
the cargo bed. Just unlock the quick release latches
located in the back of the seat.
1. Remove the safety belt hooks connecting to
the hoops bolted on the frame.
a) Press the limiting rock, make a space between
the hook and the hoop.
b) Take off the hook.
2. Repeat step 1, take off these hooks behind seat and both sides of seat.
3. Unlock the seat locker under the seat.
4. Turn the seat until it is stopped by steering wheel.
Fuel tank
Fuel tank cap
Seat lock
Left seat
Right seat
