Joyner TROOPER-T2 - Parking

193
6. Parking
Ref
ERP code
Part No. Part Description Qty
1 02.DLJ.ZJ610.04-00/14 ZJ610.04-00/14 Master cylinder assy 1
2 02.TR1100.07.02.01.01A TR1100.07.02.01.01A Outlet hose of
master cylinder
1
3 02.TR1100.07.02.01.02A TR1100.07.02.01.02A
Right outlet hose of
“T”connection
1
4 02.DLJ.ZJ509.05-00R ZJ509.05-00R Right caliper assy 1
5 02.DLJ.ZJ609.F02-01 ZJ609.F02-01 “T” connection 1
6 02.TR1100.07.02.01.03A TR1100.07.02.01.03A
Left outlet hose of
“T”connection
1
7 02.DLJ.ZJ509.05-00L ZJ509.05-00L Left caliper assy 1
8 02.DLJ.ZJ509.03-04 ZJ509.03-04 Hydraulic brake pad 2
9 02.DLJ.ZJGS.01-02 ZJGS.01-02 Hose bolt M10x1.25 6
10 02.DLJ.ZJGS.01-01 ZJGS.01-01 Seal washer 12
11 02.TR1100.07.02.01A TR1100.07.02.01.00A
Hydraulic pump
assembly of parking
brake
1
