Joyner TROOPER-T2 - Gear-Shift Mechanism

184
4.Gear-shift mechanism
11
12
13
14
15
16
17
19
3
4
10
3
4
5
1
2
5
2
7
6
17
26
11
18
25 24 23
22
21 20
No.
ERP code
Code name Description Q'ty
18
02.SV1100.05.02.02.03
SV1100.05.02.02.03 Cuprum bearing 1
19
02.S800.04.01.02
S800.04.01.02.00-R2 5T07D1 Transmission 1
20
02.DLJ.5T07-1702063
5T07-1702063 Nylon 1
21
02.S800.05.02.04
S800.05.02.04.00-R2 Gear changing arm 1
22
02.DLJ.5T07-1702045
5T07-1702045 Small washer 1
23
02.DLJ.5T07-1702046
5T07-1702046 Big washer 1
24
03.04.93-φ8/05
93-SW8 Spring washer 8 1
25
03.02.6183,1-M8/05
6170-M8 Nut M8 2
26
02.DLJ.5T07-1702064
5T07-1702064 Rubber 1
