Joyner TROOPER-T2 - Driven Gear Assy

178
6 DRIVEN GEAR ASSY
Ref
ERP code
Part No. Part Description Qty
1
02.DLJ.5T07D1--17016
00
5T07D1--17016
00 Driven gear assy
1
2
02.DLJ.5T07-1701310
5T07-1701310 Front bearing of differential 1
3
02.DLJ.QR512-1701604
QR512-1701604 Driving gear of odometer 1
4
02.DLJ.4T08A-1701602
4T08A-1701602 Front bearing of output shaft 1
5
02.DLJ.4T08A-1701601
4T08A-1701601 Output shaft 1
6
02.DLJ.4T08A-1701603
4T08A-1701603 Connecting disc 1
7
02.DLJ.QR512-1701611
QR512-1701611 Driven gear of speed reducer 1
8
02.DLJ.4T08A-1701605
4T08A-1701605 Rear bearing of output shaft 1
9
02.DLJ.5T07-1701320
5T07-1701320 Rearing bearing of differential 1
10
02.DLJ.5T07-1701309
5T07-1701309 Flange bolt 8
11
02.DLJ.MQC4-2303016
MQC4-2303016 Retaining ring 2
12
02.DLJ.5T07-1701090
5T07-1701090 Right seal of differential 1
13
02.DLJ.5T07-1701010
5T07-1701010 Left seal of differential 1
14
02.DLJ.QR512-1701605
QR512-1701605
Right seal adjusting washer of
differential
depen
d
