177
7
02.DLJ.5T07－1702107A 5T07－1702107A
Stop plate of shift interlock 1
8
02.DLJ.5T07－1702105A 5T07－1702105A Shift－select arm.
1
9
02.DLJ.QR512－1702113 QR512－1702113
Spring pin 3.5x28 1
10
02.DLJ.5T07－1702106 5T07－1702106 Pin of shift－select arm
1
11
02.DLJ.5T07－1702114A 5T07－1702114A
Release spring of 5
TH
&
reverse gear
1
12
02.DLJ.5T07－1702112 5T07－1702112
Release－spring seat of 5
TH
&
reverse gear
1
13
03.07.879-3×22/05 879.1－P3x22
Pin 3x22 1
14
02.DLJ.5T07－1702108A 5T07－1702108A
Seat of reverse gear spring 1
15
02.DLJ.5T07－1702109A 5T07－1702109A
Limiting spring reverse gear
1
16
02.DLJ.QR512 －
1702111A
QR512－1702111A
Limiting cam of reverse gear
1
17
03.07.879-5×22/05 879.1－5x22
Pin 5x22
1
18
02.DLJ.QR512－1702070 QR512－1702070
Guide case assy of shift －
select shaft
1
19
02.DLJ.QR512－1702071 QR512－1702071
Guide case of shift － select
shaft
1
20
02.DLJ.5T07－1702072 5T07－1702072
Stop plate of release spring 1
21
03.01.5787-M6×12/05 5787－Mx12
Flange bolt M6x12 2
22
02.DLJ.QR512－1702227 QR512－1702227
SHIFT－SELECT SHAFT OIL
SEAL
1
23
02.DLJ.5T07－1702062 5T07－1702062
Anti － dust cover of shift －
select shaft
1
24
02.DLJ.5T07－1702073 5T07－1702073
Limiting bolt of reverse gear 1
25
02.DLJ.QR512－1702229 QR512－1702229
Washer of limiting bolt 1
26
03.07.882-6×12/05 119－P6x12
Pin B 6x12 2
27
03.01.5787-M8×20/05 5787－M8x20
BOLT AM 8x20 4
28
02.DLJ.5T07－1702065A 5T07－1702065A
Limiting bolt of shift 1
29
02.DLJ.QR512－1702229 QR512－1702229
Washer of limiting bolt 1
30
03.01.5787-M8×75/05
5787－M8x75
Flange bolt M8x75 1
31
02.DLJ.5T07－1702063 5T07－1702063
Shift pushing block 1
32
02.DLJ.5T07－1702062 5T07－1702062
Anti－dust cover 1
33
03.02.6183,1-M8/05
6170－M8
Nut M8 1
34
03.04.93-φ8/05 93－SW8
Spring washer 8
1
35
02.DLJ.5T07－1702046
5T07－1702046 Big washer of shift arm 1
36
02.DLJ.5T07－1702045 5T07－1702045
Small washer of shift arm
1
37
02.S800.05.02.04
S800.05.02.04.00－R2
Gear changing arm 1
38 02. SV1100.05.02.02.03 SV1100.05.02.02.03 Cuprum bush 1
39
02.DLJ.5T07－1702047 5T07－1702047 Anti－dust washer of shift arm
1
40
02.S800.05.02.05.
S800.05.02.05.00－R2
Choosing gear arm mount
1
41
02.S800.05.02.04
S800.05.02.04.00－R2
Gear changing arm
1
42
03.07.879-5×28/05 879.1－P5x28
PIN 5x28
1
43
02.S800.05.02.06
S800.05.02.06.00－R2
Gear cable mount 1
