31
Winch switch “in/out”
Set the winch to IN to reel the cable in
Set the winch to OUT to reel the cable out.
Indicator lights
Reverse indicator light “R”
This indicator light comes on when the drive select lever is “R” reverse position.
Battery charging indicator light “ ”
This indicator light comes on when the generator of the engine can’t electricize the
battery. You should check the generator and battery or get help from your JOYNER
dealer.
Coolant temperature indicator light “ ”
It indicates the temperature of coolant. if the temperature is above 102
0
C/215
0
F, stop
engine immediately. Check coolant lever and add if low, see authorized JOYNER dealer
if temperature indicator stay on and overflow tank is full of coolant.
Oil pressure indicator light “ ”
It indicates over low/over high oil pressure when illuminated, see authorized JOYNER
dealer if necessary.
Steering wheel
Steering wheel is used to control the direction; it can be turned about third four rounds.
Be familiar with the steering wheel before driving,
and slow down less than 20 km/h when turn a
direction, or turning over may occur.
Check the steering wheel before driving, and
make sure it can work well, and front wheels can
turn according to the steering wheel.
Steering wheel
