97
6.3. Installation of new lubricating oil collecting and
filtering device, oil pump collecting and filtering
device
[Torque] 6±1N*m/4.4±0.7Ft_Lb
6.4. Assembling of oil pan
6.4.1. Clear the mating surface with the cylinder body
6.4.2. Apply sealing silica before assembling
[Grease] Letai 5699
Attention
·The liquid cushion with silica line diameter of
Ф3-4mm/Ф0.1181-0.1574inch, without any broken section
·Make the assembly in 15 minutes after the
application of silica
6.4.3. Tighten in the sequence shown in the right
figure with the torque of 6±1N*m/4.4±0.7Ft_Lb from the center to
the two sides
Front
Rear
