73
XP7202 Instruction Manual
The Input Select function is used to select the switch
input for the gyro gain and the channel that will operate
the gyro gain.
The Auxiliary 2 channel options are:
INH: Inhibit is selected if the gyro function will not be
used on the Aux 2 channel
F.MODE: In this mode the AUX2 channel is controlled by
the flight mode switch and three positions are
available. Sub trim and travel adjust is used to
set the center and end points for each switch
position.
AUX2: The Auxiliary 2 switch controls the AUX2
Channel GYRO: The gyro mode is selected if
you want to use the gyro sensing programming
(see page 97) for more detail. Selecting GYRO
under AUX2 assigns the gyro sensing program
to operate use the AUX2 channel. In this case
the gyro gain must be plugged into the AUX2
Channel 7) channel.
The gear channel options are:
INH: Inhibit is selected if the gyro function will not be
used on the gear channel. Selecting inhibit turns
off the gear channel allowing it to be used as a
slave channel for mixing.
GEAR: Gear is selected if the gyro gain or retractable
gear position is to be selected using the gear
switch
GYRO: Gyro is selected under gear if you wish to have
the gyro sensing program (page 97) operate
using the gear channel.
AUX2: The Auxiliary 2 switch is used to activate the
gear position.
Input Select
To Select the Input Switch for the AUX2 Channel
Press the Down and Select keys simultaneously then
turn on the transmitter.
Press the UP or Down key until the INPUT SELECT
function appears on screen.
Press the Select key until AUX2 is highlighted.
Press the IncreaSe or DecreaSe key to select the
desired switch.
To select the input switch for the Gear channel:
Press the Down and Select keys simultaneously then
turn on the transmitter.
Press the UP or Down key until INPUT SELECT
appears on screen.
Press the Select key until GEAR is highlighted.
Press the IncreaSe or DecreaSe key to select the
desired switch.
