85
XP7202 Instruction Manual
The swashplate Mix screen is only displayed when a
CCPM swashplate mix is activated is Swash Type (see
Page 74) Swashplate Mix adjust the amount and direction
of travel for the aileron, elevator and pitch functions. For
example if more aileron travel is desired increasing the
aileron swashplate mix value will increase the overall travel
of the servos necessary to achieve greater aileron throw.
Note that negative values are available which will reverse
the direction of that function.
Swashplate Mixing
Accessing the Swashplate Mix Function
Press the Down and Select keys simultaneously to
access the Function Mode.
In function mode press the UP or Down key to select the
SWASH MIX screen
Press the Select key to access the desired function
(aileron, elevator, pitch or expo)
Press the IncreaSe or DecreaSe key to change the
selected swashplate mix value.
NOTE
: Selecting a negative value will reverse the
direction of the function.
