86
XP7202 Instruction Manual
The Throttle Hold function is used to practice autorotation
with glow/gas powered helicopters and is often use as a
safety switch for electric helicopters holding the throttle in
the off position. When the throttle hold switch is activated
the throttle hold function holds the throttle servo/ ESC in
a specific position (normally low or off throttle) while all
other servos function normally.
Press the Down and Select keys simultaneously to
access the Function Mode
In Function Mode, use the UP or Down key to select the
THRO HOLD screen.
Press the IncreaSe or DecreaSe key to activate the
throttle hold function
Throttle Hold
[THRO HOLD]
HOLD POS.
ACT
OFF
- 5.0%
Press to enter
Function Mode
Press to enter THROTTLE HOLD
Press to activate THROTTLE HOLD
and change values
Press to select
desired channel
Press to return
value to default
To Access the Throttle Hold Function
When activated press the IncreaSe or DecreaSe key
to change the throttle hold value.
Move the selected channel’s Stick or switch in the desired
direction that you wish to adjust.
Press the IncreaSe or DecreaSe keys to adjust the
sub-trim position for that selected channel’s direction.
