XP7202 Instruction Manual
Auto Dual Rate EXP
To Adjust the Auto Dual Rate
Press the Down and Select key simultaneously to
access the Function Mode.
Press the UP or Down key until the AUTO D/R EXP
screen appears on screen.
Use the Select key to select NORMAL, ST1 ST2 or
HOLD FLIGHT
mode.
When selected, press the IncreaSe or DecreaSe key
to select DUAL RATE, P-1, P-2 or INHIBIT.
NOTE
: The actual dual rate values are set in the Dual
Rate and Expo screen. See Page 85.
[AUTO D/R EXP]
◊NORM INH
ST-1 INH
ST-2 INH
Press to enter
Function Mode
Press to enter AUTO DUAL RATE
Press to adjust value
Press to select
desired channel
Press to return value to
default setting
The Auto Dual Rate and Expo function allows Expo and
Dual Rate values (aileron, elevator and rudder) to be
automatically selected in each flight mode (Normal, ST1,
ST2, and Hold. When an auto dual rate flight mode is
inhibited, the dual rate is defaulted to correlating switch or
the dual rate switch positions.
