JR XP7202 User Manual

83
XP7202 Instruction Manual
The Sub-Trim function allows you to electronically adjust
the centering of each servo. Sub-trim is individually
adjustable for all seven channels, with a range of + or -
125% (+ or – 30 degrees servo travel).
Press the Down and Select keys simultaneously to
access the Function Mode
In Function Mode, use the UP or Down key to select the
SUB TRIM screen.
Press the Select key to access the desired channel
Press the IncreaSe or DecreaSe keys to adjust the
sub-trim position for that selected channel.
Sub-Trim
To Access the Sub-Trim Function
CAUTION
: Do not use excessive sub-trim values as
it is possible to overdrive the servo’s maximum travel.
Sub-trim value (max ±125)
[SUB TRIM]
≥THRO AILE
0 0
0 0
ELEV RUDD
Press to enter
Function Mode
Press to enter SUB TRIM
Press to adjust servo position
Press to select
desired channel
