82
XP7202 Instruction
Manual
The Reverse
Switch
function
allows electronic
means
of
reversing the
ser
vo’
s throw
. Ser
vo
reversing is
available
for
all seven
channels.
Press the
Sel
ec
t
key to
access
the desired
channel
Press the
Incr
e
aSe
or
DecreaSe
keys
to reverse
the
servo
direction
for that
selected
channel.
THRO Throttle
AILE
Aileron
ELEV Elevator
RUDD
Rudder
GEAR gyro
gain,
PIT
.
pitch
(Aux1) gyro
gain
Reverse
Switch
Accessing
the Reverse
Switch
Function
[REVERSING SW]
NORM
GEAR
≤
ch 1 2 3 4 5 6 7
REV.
Press to
enter
Function Mode
Press to
enter
REVERSE
Press to
select
REV
.
or
NORM
Press to
select
desired channel
81
83
