JRC JMA-5204 - Cursor Modes (Cursor)

5.1 PREPARATION
ņ12
5
yy
yyy
5.1.4 Cursor Modes (Cursor)
Types and Functions of Cursor Modes
The types of cursor modes are listed in the table below. To use the function of a cursor mode, move the cursor
onto the PPI object and press the [ENT] key.
Mode Function
ACQ TT Enables the target tracking function to acquire a target in manual mode.
ACT AIS Activates AIS targets, deactivates AIS target and sets a point filter.
TGT Data Select or deselect a tracking or AIS target whose numerical data is to be displayed.
Cancel Cancels a target tracking.
Mark Puts a temporary mark.
Change of Cursor Mode
Procedure 1 Move the cursor to the cursor mode Cursor (software button
ձ
located at the top right corner of the radar display described in Section
2.3.3), and press the [ENT] key.
The selected cursor mode will be shown at the cursor mode (software button ղ located
at the top right corner of the radar display described in Section 2.3.3).
