11.23 EQUIPMENT DISTANCE BETWEEN
OTHER INSTRUMENTS
Maximum
(1) LCD monitor to processor unit 5m
(2) Keyboard unit to processor unit 5m
(3) Scanner to display unit (4kw NKE-2043 12VDC) 20m
(4) Scanner to display unit (4kw NKE-2043 24V/32VDC) 30m
(5) Scanner to display unit (6kw NKE-2062/2063A 12VDC) 20m
(6) Scanner to display unit (6kw NKE-2062/2063A 24V/32VDC) 30m
(7) Scanner to display unit (6kw NKE-2062HS 24VDC) 30m
(8) Scanner to display unit (10/25kw) 65m
11.24 OTHERS (OPTION)
x Equipment cable 4/6/10/25 kW type (connectors on both ends)
Cable length:
10m CFQ-6912-10/15m CFQ-6912-15
20m CFQ-6912-20/30m CFQ-6912-30
40m CFQ-6912-40/50m CFQ-6912-50
65m CFQ-6912-65
x TT unit NCA-877A
x NSK unit NCT-4106A
x AIS unit NQA-2155
x Plotter unit NDB-44
x X band performance monitor NJU-85
x Display stand MPBX42944
x Horizontal sun visor for NWZ-164 MPOL30369
x Vertical sun visor for NWZ-164 MPOL30370
x Simple ISW cable CFQ-5251 (5 m)
x Sub-monitor lead cable CFQ-5350 (7ZCRD1153)
x ISW/sub-operation unit lead cable CFQ-5351 (7ZCRD1152)
x NMEA lead cable CFQ-5352 (7ZCRD1212)
x NMEA lead cable 2 CFQ-5462 (2CH pair for transmission and receive)
x Cable between connected NMEA units CFQ-6560 (10 m)
x JLR-10 connection cable CFQ-6934 (10 m)
x JLR-20/30 connection cable CFQ-5469
x Keyboard extension cable CFQ-6999 (10 m)
x NDW-51 connection cable CFQ-7082
x Coast line ROM card
x Memory card
x Rectifier unit NBA-5111
