APPENDIX
FIGURE 1 JMA-5204, JMA-5208/HS, JMA-5209, JMA-5212-4/6/4HS/6HS,
JMA-5222-7/9 BLOCK DIAGRAM
FIGURE 2 JMA-5204 INTER-CONNECTION DIAGRAM
FIGURE 3 JMA-5208/HS INTER-CONNECTION DIAGRAM
FIGURE 4 JMA-5209 INTER-CONNECTION DIAGRAM
FIGURE 5 JMA-5212-4/6/4HS/6HS INTER-CONNECTION DIAGRAM
FIGURE 6 JMA-5222-7/9 INTER-CONNECTION DIAGRAM
FIGURE 7 PRIMARY POWER SUPPLY DIAGRAM, TYPE JMA-5204, JMA-5208/HS,
JMA-5209, JMA-5212-4/6/4HS/6HS, JMA-5222-7/9
FIGURE 8 PROCESSOR UNIT, NDC-1460 INTER-CONNECTION DIAGRAM
FIGURE 9 KEY-BOARD UNIT, NCE-7699A INTER-CONNECTION DIAGRAM
FIGURE 10 NKE-2043 SCANNER UNIT INTERCONNECTION DIAGRAM
FIGURE 11 NKE-2062 SCANNER UNIT INTERCONNECTION DIAGRAM
FIGURE 12 NKE-2062HS SCANNER UNIT INTERCONNECTION DIAGRAM
FIGURE 13 NKE-2063A SCANNER UNIT INTERCONNECTION DIAGRAM
FIGURE 14 NKE-2103 SCANNER UNIT INTERCONNECTION DIAGRAM
FIGURE 15 NKE-2254 INTERCONNECTION DIAGRAM OF SCANNER UNIT
FIGURE 16 JMA-5200MK2 ON-SCREEN CONTROLS
