1.3 CONFIGURATION
1ņ4
1
y
1.3 CONFIGURATION
Scanners and Transmitted Output Powers
SCANNER TYPE
TRANSMITTED
OUTPUT POWER
BAND
RATE OF
ROTATION
CATEGORY
JMA-5204
620mm
RADOME
4 KW X 27rpm
JMA-5208
3.9FT SLOT
ANTENNA
6 KW X 27rpm
JMA-5209
3.9FT SLOT
ANTENNA
6 KW X 27rpm
JMA-5212-4
4 FT SLOT
ANTENNA
10 KW X 27rpm CAT 3
JMA-5212-6
6 FT SLOT
ANTENNA
10 KW X 27rpm CAT 3
JMA-5222-7
7 FT SLOT
ANTENNA
25 KW X 24rpm CAT 3
JMA-5222-9
9 FT SLOT
ANTENNA
25 KW X 24rpm CAT 3
JMA-5208HS
4FT SLOT
ANTENNA
6 KW X 48rpm
JMA-5212-4HS
4 FT SLOT
ANTENNA
10 KW X 48rpm
JMA-5212-6HS
6 FT SLOT
ANTENNA
10 KW X 48rpm
Radar Configuration and Ship’s Mains
RADAR
MODEL
SCANNER
UNIT
PERFORMANCE
MONITOR UNIT
DISPLAY UNIT SHIP’S MAINS
JMA-5204 NKE-2043 - NCD-4380 12/24/32V DC #1
JMA-5208 NKE-2062 - NCD-4380 12/24/32V DC #1
JMA-5209 NKE-2063A - NCD-4380 12/24/32V DC #1
JMA-5212-4 NKE-2103-4 NJU-85 NCD-4380 24V DC
JMA-5212-6 NKE-2103-6 NJU-85 NCD-4380 24V DC
JMA-5222-7 NKE-2254-7 NJU-85 NCD-4380 24V DC
JMA-5222-9 NKE-2254-9 NJU-85 NCD-4380 24V DC
JMA-5208HS NKE-2062HS - NCD-4380 24V DC
JMA-5212-4HS NKE-2103-4HS NJU-85 NCD-4380 24V DC
JMA-5212-6HS NKE-2103-6HS NJU-85 NCD-4380 24V DC
Notes:
1. An optional rectifier NBA-5111 is necessary for using Ship's Mains 100/110/115/200/220/230 V AC.
2. The scanner unit except NKE-2043/2062/2063A/2103 series can be equipped with a deicing heater as
an option, and '-D' shall be suffixed to the type name.
(e.g. NKE-2254-7D, NKE-2254-9D).
