1.5 GENERAL SYSTEM DIAGRAMS
1ņ1
y
1.1 FUNCTIONS
This equipment is a high-performance radar equipment consisting of a scanner unit, a transmitter-receiver unit
and a high resolution color LCD display unit.
1.1.1 Function of This System
The JMA-5200MK2 series is a color radar system designed to comply with the international standards.
The JMA-5200MK2 series (except JMA-5204/5208/5208HS/5209) meets the requirements of IMO
Res. MSC.192(79), MSC.191(79), A.694(17) for SOLAS ships.
JMA-5204/5208/5208HS/5209 meets the general requirements for radio and navigational equipment
(IMO Resolution A.694(17)) and IEC 62252 for NON-SOLAS ships.
The main functions include:
x sensitivity adjustment
x sea clutter and rain/snow clutter suppression
x interference rejecter
x bearing and range measurement using a cursor, fixed/variable range markers, and electronic bearing
line
x own track display
x NAV line and marker displays
x TM (True Motion) presentation
x self-diagnostic facilities
x radar performance monitoring (Performance Monitor)(option)
x TT functions (manual/automatic, target acquisition and tracking, vector and trail displays and alarm
displays) (option)
x simple plotter functions (marker and line display, destination/route setting) (option)
