System Mode
17
Auxiliary Channel 3 Function Select
The Auxiliary Channel 3 function of the XS3 allows you to
select from two different types of Channel 3 servo travel
movements or to inhibit the Auxiliary Channel 3 function.
Use the information below to select the correct Auxiliary
Channel 3 function type for your particular installation. It is
suggested the 0 function be selected for most applications.
(Factory preset)
00
= The 0 or Inhibit function allows the Brake End-Point
Adjustment function to be used. This function is designed
to be used with most types of electric and gas-powered RC
cars. This feature is extremely popular, as it allows the
amount of panic braking accessible through the throttle
trigger’s braking position to be adjusted during
operations for maximum effectiveness. When activated, the
braking values will be visible via the Direct Trim function,
page 29.
LLNN
= The LN or linear servo travel function is designed to
be used when an engine fuel mixture servo is required. This
function is most commonly used with gas-powered
RC racing boats and is accessible through Grip Dial A. In
this function, the maximum travel of the servo is deter-
mined by the End-Point Adjustment function. The servo
neutral position can be altered proportionally via the Grip
Dial A for mixture adjustment. When activated, fuel mixture
trim values are visible for the Direct Trim function, page 32.
aux
0
Auxiliary Channel 3
Function
Channel 3 is Inhibited
(Grip Dial A braking
function is now
activated)
aux
LN
Auxiliary Channel 3
Function
Linear Movement
(fuel mixture servo)
22PP
= The 2P or 2 position Servo Travel function is
designed to be used as a transmission gear shift channel.
This feature is designed for use with vehicles such as the
Traxxas® T-Maxx. This function is accessible through Grip
Button C or Grip Dial A if Grip Button C is occupied by
another function. In this function, the servo’s travel values
are determined by the End-Point Adjustment function.
aux
2P
Auxiliary Channel
3 Function
Non-linear
Two-Position
Movement
(Traxxas shiftable
transmission use)
Accessing the Auxiliary Channel 3 Function
1.Press the Scroll and Channel keys at the same time and
hold.
2.Turn on the transmitter power switch to enter System
mode.
3.Press the Scroll key until “AUX” appears on the screen.
4.Press the Increase or Decrease key to select the correct
Auxiliary Channel 3 function type to be used.
5.Press the Scroll key to access the Grip Button C Select
function.
6.To exit the System mode, either turn the transmitter
power switch off or press the Scroll and Channel keys at
the same time.
Press and hold the Scroll and Channel keys at the
same time to enter the System mode. Next Press the
Scroll key until "AUX" appears.
Press the Increase or Decrease key to select the
desired Auxiliary channel 3 function type to be used.
0 = Inhibited (Grip Dial A braking is active)
LN = Linear servo movement
2P = 2-position servo movement
SCROLL
ENTER
CHANNEL
INCREASE
CLEAR
DECREASE
