System Features
6
System Specifications
Transmitter
• 3 channels
• Synthesized PLL Channel Selection via software
• FM modulation
• Easy-to-read LCD graphics display
• 6-model memory
• 3-character model name entry
• Electronic digital trim levers for throttle and steering
• Two assignable electronic grip levers
• Auxiliary third channel accessible through
Grip Lever A
• Direct display trim function
• Servo reversing
• Sub-trim
• Steering dual-rate
• Exponential (steering and throttle)
• Steering end-point adjustment
(two points: left and right)
• Brake/throttle end-point adjustment
• Throttle deadband adjustment
• 50-lap timer
• Low-battery alarm
• Charge jack receptacle (rechargeable batteries not
included; order JRPB958)
RS300 Receiver
• 3 channels
• Synthesized PLL Channel Selection
• FM modulation
• 27MHz/75MHz available
• Battery Eliminator Circuitry (BEC)
• Patented ABC&W interference technology
Z590M Servo
• Metal gears for durability
• Great high-torque car/buggy steering servo
• Indirect drive feedback potentiometer for additional
vibration protection
• Surface Mount Technology (SMT)
Z270 Servo
• Low current drain
• Indirect drive feedback potentiometer for additional
vibration protection
• Surface Mount Technology (SMT)
• Durable nylon gear train
Components
Transmitter XS3
Receiver RS300
Servos Z590M x 1
Z270 x 1
Accessories BEC switch harness with battery case,
servo accessories (for each servo),
instruction manual
XS3 Transmitter
Model number XS3
Encoder 3-channel computer system
RF output 27MHz/75MHz synthesized
Modulation FM
Output power 130 mW
Current Drain 180 mA
Power source 1.5V x 8 dry cell
(1.2V x 8 Ni-Cd optional)
Output pulse 1000–2000 (1500 neutral)
RS300 Synthesized Receiver
Model number RS300
Type 3-channel/FM ABC&W circuitry
Frequency 27MHz/75MHz
Sensitivity 5 qs minimum
Selectivity 8 KHz/50 dB
Weight .9 ounces
Size (LxWxH) 1.75” x 1.25” x 0.63”
Receiver Antenna 20”
Power supply 4.8–6.0V DC
Channel selection Rotary dial
Z270 Servo
Torque 49 ounce inch (@6.0V)
Speed .19 sec/60° (@6.0V)
Weight 1.50 ounces
Size (WxLxH) 0.73” x 1.51” x 1.37”
Motor 3-pole ferrite
Gears Nylon
Z590M Servo
Torque 85 ounce inch (@6.0V)
Speed .15 sec/60° (@6.0V)
Weight 1.6 ounces
Size (WxLxH) 0.73” x 1.55” x 1.46”
Motor 3-pole ferrite
Gears Metal
