Function Mode
Programmable Mixing
The XS3 offers two different mixing adjustments that allows
for mixing one channel to another channel. The mixes
available are Steering-to-Auxiliary Channel Mixing and
Throttle-to-Auxiliary Channel Mixing. Each direction is
independently adjustable. Popular use of this function
includes 4-wheel steering and independent front and rear
wheel brakes.
For example, Throttle-to-Auxiliary channel mixing can be
used for independent front and rear wheel brakes. Each
time the throttle/brakes is moved, the auxiliary channel will
move in the direction and to the value input being given by
the throttle channel. Mixing is proportional, so small inputs
to the throttle will result in small output from the auxiliary
channel. The adjustment range is from -125% to 0% to
125%. If the rate is negative, the channel is mixed in the
opposite direction.
Both mixes share a single mixing “offset.” The purpose of
the mixing offset is to redefine the neutral position of the
auxiliary channel, which can be set using Grip Lever A
when “LN” is selected in the Auxiliary Channel 3 function.
If the “LN” selection is turned off in the Auxiliary Channel 3
function with a offset value currently present, the value will
continue to act as a mixing offset until the value is either
cleared or changed. If a mix is not required, it is strongly
suggested the mixing rate be set for 0%, which is the
default.
Accessing The Mixing Adjustment Function
1.Turn on the transmitter power switch.
2.Press the Scroll key to enter Function mode.
3.Press the Scroll key until “MIX” appears in the screen.
4.Press the Channel key to select the desired mix to be
used.
STR or STL = Steering-to-Auxiliary Channel 3 Mixing.
THF or THB = Throttle-to-Auxiliary Channel 3 Mixing.
5.Move the steering wheel or trigger in the desired direc
tion for adjustment (left/right, forward/reverse or brake).
Press the Increase or Decrease key to achieve the
desired amount of mixing. Move the wheel or trigger in
the opposite direction to adjust the mixing in the oppo
site direction.
6.Press the Scroll key to access the Lap-Timer function
(if enabled) or Sub-Trim function.
7.To exit the Function mode, either turn off the transmitter
power switch or press the Scroll and Channel keys at the
same time.
Steering-to-Auxiliary
Channel Mixing
Adjustment
Throttle-to-Auxiliary
Channel Mixing
Adjustment
—
stl
MIX
thb
MIX
10
∞
10
∞
SCROLL
ENTER
CHANNEL
INCREASE
CLEAR
DECREASE
Press the Scroll key until "MIX" appears on the
screen. Press the Channel key to select the desired
mix.
Move the wheel or trigger in the desired direction
and press either the Increase or Decrease keys to
achieve the desired mixing value.
25
