Accessing the Direct Trim Mode
The Direct Mode function of the XS3 is accessible through
the use of the electronic throttle or steering trim levers, as
well as the two electronic grip levers (A&B) located on the
upper portion of the grip handle. This function allows for
quick trim adjustment of these controls.
stc
0
thc
0
stg
70
∞
RATE
Steering Trim
(page 30)
Throttle Trim
(page 30)
Steering Dual-Rate
(Grip Lever B)
(page 31)
TRIM
TRIM
aux
0
brk
50
EPA
Only present when Aux. function “O” is selected
Only present when Auxiliary function “LN” is selected
Brake Travel Adjustment
(Grip Lever A), (page 32)
(Only visible when the
Auxiliary Channel 3
function “O” has been
selected.) Refer to
Auxiliary Channel 3
function, page 17, for
clarification.
Auxiliary Channel 3
Trim Adjustment
(LN mode only)
Refer to Auxiliary
Channel 3 function,
page 32, for
clarification.
R/B
*Note: When Auxiliary Channel 3 function 2P is
selected, the two screens above are not present.
To access the Direct Trim Mode function, turn on the trans-
mitter power switch. Next, move the desired trim lever to be
adjusted. The appropriate screen for the selected trim
lever will be displayed. To adjust, simply move the trim
lever in the desired direction until the correct amount of
trim is achieved. Once the desired trim is achieved, the
screen will return to the Normal display screen after
approximately two seconds from the last trim input. If the
Increase or Decrease keys are pressed any time during the
two seconds, the system will return to the previous screen
in use.
29
*
*
