JRRacing XS3 - End-Point (Travel) Adjustment

4
Throttle Adjustment
4.Press the Channel key once. “TH” will appear on the
screen.
5.Pull the trigger forward or push the trigger for brake
adjustment.
6.Press the Increase or Decrease keys to select the
desired travel value.
Auxiliary Channel 3 Adjustment
If a third channel is not required, proceed to Step 9.
7.Press the Channel key once. “AUX” will appear on the
screen.
8.Press the Increase or Decrease keys to select the
desired travel value.
9.Press the Scroll and Channel keys at the same time to
exit the function mode.
End-Point (Travel) Adjustment
1.From the Servo Reverse function, press the Scroll key
three times to access the End-Point (Travel) Adjustment
function (the EPA screen with “ST” will appear).
Steering Adjustment
2.Rotate the steering wheel in the desired direction (left or
right) to be adjusted.
3.Press the Increase or Decrease keys to select the
desired travel value.
CHANNEL
SCROLL
INCREASE
CLEAR
DECREASE
INCREASE
CLEAR
DECREASE
INCREASE
CLEAR
DECREASE
st
R/B
100
EPA
Adjustment Position
ST = Steering
TH = Throttle
AUX = Auxiliary Channel 3
(optional)
Current Value
L/F = Left/Forward
R/B = Right/Brake
