25
4.8. Attaching the needle
Needles to be purchased
When purchasing spare needles,
specify HA×1 (130/705H) or HA×1 SP
(needle for knits) .
Checking the needle
Check the needle for its straightness occasionally.
Any bent needle would cause skipped stitches, thread breakage or damage
to materials.
The at part of the needle
Flat object
Needle size:
The larger the number, the thicker the needle.
If the needle is not properly installed or a bent
needle is used, needle breakage can be caused.
It will cause damage to the machine.
Attention:
Removing needle
Turn the hand wheel towards you until the needle
comes to the highest position and lower the presser
foot.
Turn the needle setscrew
towards you 1-2 times
and remove the needle.
T-shape screwdriver
Attaching the needle
Hold the needle with its at part facing away from you
(
), and insert it fully until it touches the stopper pin
.
Securely tighten the needle setscrew.
The needle cannot be inserted unless it is cor-
rectly positioned.
Turn off the machine or leave the
Machine in Lock Mode
