28
Set the bobbin on the bobbin winding
shaft
❸
.
4
5
Pay attention that the thread from bobbin
winding thread guide is not loose and
wind the thread to the bobbin 4-5 times in
clockwise direction.
Put the thread end into the guide
❹
at
the bobbin winding shaft and pull it to the
right side to cut it.
8
Push the bobbin winding regulator
❺
towards the bobbin to start winding the
bobbin.
* Be careful that the bobbin winding regulator
works as a switch.
7
When winding is nished, the shaft
stops automatically, the bobbin winding
regulator moves to right and return to the
original position.
Remove the bobbin from the bobbin
winding shaft and cut the thread by cutter
❻
.
* Bobbin winding will automatically stop even
while winding, when the winding speed is
reduced due to a load to the bobbin winding
motor caused by thread tangling.
❺
❸
❹
❻
6
Turn the power ON.
