– 30 –
166 Selection of The high-speed switch function is toggled. 0/1 S
high-speed 0 : Switch of normal high speed
switch function 1 : Switch of needle up/down compensation with
one-touch operation while sewing stops
167 Presence/
The remaining bobbin thread detection device is used.
0/1 U 45
absence of 0 : Function disabled
remaining 1 : Function enabled
bobbin thread The bobbin thread counter regularly works regar
detection dless of the setting.
168 Remaining The function settings of the remaining bobbin thread 0/1 U 45
bobbin thread detection device are performed.
detection Perform the settings with reference to Instruction
function Manual for the remaining bobbin thread detection
device.
169 Time of air blow Time of air blow to remaining bobbin thread 0 to 200 S 45
to remaining detection device (after thread trimming) 0 (ms)
bobbin thread
detection device
170 Brake angle at The angle when brake is applied at down position 0 to 180 S 45
down side stop stop (from down detection) (°)
190 33 V switching Setting of the output duty provided to the machine 10 to 90 S 45
duty setting head supporting 24 V solenoid output (DNU-1541) (%)
is performed.
192 Password lock Once this function is activated, stitching count, 0 to 9999 S 45
function reverse feed stitching, and one-touch operation
cannot be specified.
No. Item Description Setting range Setting level
(Start level ; U : User’s mode, S : Service mode)
