JUKI SC-922 Engineer's Manual

No. Signal Function Pin No. Remarks
10 — Output is disabled.
21 O01 hled1 At-hand LED 1 CN44 15
32 O02 hled2 At-hand LED 2 CN44 16
43 O03 hled3 At-hand LED 3 CN44 17
54 O04 hled4 At-hand LED 4 CN44 18
65 O05 hled5 At-hand LED 5 CN44 19
76 O06 hled6 At-hand LED 6 CN44 20
87 O07 hled7 At-hand LED 7 CN44 21
98 O08 hled8 At-hand LED 8 CN44 22
10 9 O09 opo1 OP outputput 1 CN59 11
11 10 O10 opo2 OP outputput 2 CN59 12
12 11 O11 opo3 OP outputput 3 CN59 13
13 12 O12 opo4 OP outputput 4 CN59 14
14 13 O13 opo5 OP outputput 5 CN59 15
15 14 O14 opo6 OP outputput 6 CN59 16
16 15 O15 opo7 OP outputput 7 CN59 17
17 16 O16 opo8 OP outputput 8 CN59 18
18 17 O17 opo9 OP outputput 9 CN59 19
19 18 O18 opo10 OP outputput 10 CN59 20
20 19 O19 opo11 OP outputput 11 CN59 21
21 20 O20 opo12 OP outputput 12 CN59 22
22 21 O21 opo13 OP outputput 13 CN59 23
23 22 O22 opo14 OP outputput 14 CN59 24
24 23 O23 opo15 OP outputput 15 CN59 25
25 24 O24 opo16 OP outputput 16 CN59 26
26 25 O25 opo17 OP outputput 17 CN51 15
27 26 O26 opo18 OP outputput 18 CN51 16
28 27 O27 opo19 OP outputput 19 CN51 17
29 28 O28 opo20 OP outputput 20 CN51 18
30 29 O29 opo21 OP outputput 21 CN51 19
31 30 O30 opo22 OP outputput 22 CN51 20
32 31 O31 opo23 OP outputput 23 CN51 21
33 32 O32 opo24 OP outputput 24 CN51 22
No. Signal Function Pin No. Remarks
10 — Disabled Input is disabled.
21 O01 hled1 At-hand LED 1 — — The output signal of the at-hand LED_1 can be internally entered.
32 O02 held2 At-hand LED 2 — — The output signal of the at-hand LED_2 can be internally entered.
43 O03 hled3 At-hand LED3 — — The output signal of the at-hand LED_3 can be internally entered.
54 O04 hled4 At-hand LED 4 — — The output signal of the at-hand LED_4 can be internally entered.
65 O05 hled5 At-hand LED 5 — — The output signal of the at-hand LED_5 can be internally entered.
76 O06 hled6 At-hand LED 6 — — The output signal of the at-hand LED_6 can be internally entered
87 O07 hled7 At-hand LED 7 — — The output signal of the at-hand LED_7 can be internally entered
98 O08 hled8 At-hand LED 8 — — The output signal of the at-hand LED_8 can be internally entered
10 9 O09 opo1 OP output 1 — — The output signal of the optional output_1 can be internally entered.
11 10 O10 opo2 OP output 2 — — The output signal of the optional output_2 can be internally entered.
12 11 O11 opo3 OP output 3 — — The output signal of the optional output_3 can be internally entered.
13 12 O12 opo4 OP output 4 — — The output signal of the optional output_4 can be internally entered.
14 13 O13 opo5 OP output 5 — — The output signal of the optional output_5 can be internally entered.
15 14 O14 opo6 OP output 6 — — The output signal of the optional output_6 can be internally entered.
16 15 O15 opo7 OP output 7 — — The output signal of the optional output_7 can be internally entered.
17 16 O16 opo8 OP output 8 — — The output signal of the optional output_8 can be internally entered.
18 17 O17 opo9 OP output 9 — — The output signal of the optional output_9 can be internally entered.
19 18 O18 opo10 OP output 10 — — The output signal of the optional output_10 can be internally entered.
20 19 O19 opo11 OP output 11 — — The output signal of the optional output_11 can be internally entered.
21 20 O20 opo12 OP output 12 — — The output signal of the optional output_12 can be internally entered.
22 21 O21 opo13 OP output 13 — — The output signal of the optional output_13 can be internally entered.
23 22 O22 opo14 OP output 14 — — The output signal of the optional output_14 can be internally entered.
24 23 O23 opo15 OP output 15 — — The output signal of the optional output_15 can be internally entered.
25 24 O24 opo16 OP output 16 — — The output signal of the optional output_16 can be internally entered.
26 25 O25 opo17 OP output 17 — — The output signal of the optional output_17 can be internally entered.
27 26 O26 opo18 OP output 18 — — The output signal of the optional output_18 can be internally entered.
28 27 O27 opo19 OP output 19 — — The output signal of the optional output_19 can be internally entered.
29 28 O28 opo20 OP output 20 — — The output signal of the optional output_20 can be internally entered.
30 29 O29 opo21 OP output 21 — — The output signal of the optional output_21 can be internally entered.
31 30 O30 opo22 OP output 22 — — The output signal of the optional output_22 can be internally entered.
32 31 O31 opo23 OP output 23 — — The output signal of the optional output_23 can be internally entered.
33 32 O32 opo24 OP output 24 — — The output signal of the optional output_24 can be internally entered.
34 33 I33 hedsw1 At-hand SW 1 CN44 4
35 34 I34 hedsw2 At-hand SW 2 CN44 5
36 35 I35 hedsw3 At-hand SW 3 CN44 6
37 36 I36 hedsw4 At-hand SW 4 CN44 7
38 37 I37 hedsw5 At-hand SW 5 CN44 8
39 38 I38 hedsw6 At-hand SW 6 CN44 9
40 39 I39 hedsw7 At-hand SW 7 CN44 10
41 40 I40 hedsw8 At-hand SW 8 CN44 11
42 41 I41 opi1 OP input 1 CN58 15
43 42 I42 opi2 OP input 2 CN58 16
44 43 I43 opi3 OP input 3 CN58 17
45 44 I44 opi4 OP input 4 CN58 18
46 45 I45 opi5 OP input 5 CN58 19
47 46 I46 opi6 OP input 6 CN58 20
48 47 I47 opi7 OP input 7 CN58 21
49 48 I48 opi8 OP input 8 CN58 22
50 49 I49 opi9 OP input 9 CN51 4
51 50 I50 opi10 OP input 10 CN51 5
52 51 I51 opi11 OP input 11 CN51 6
53 52 I52 opi12 OP input 12 CN51 7
54 53 I53 opi13 OP input 13 CN51 8
55 54 I54 opi14 OP input 14 CN51 9
56 55 I55 opi15 OP input 15 CN51 10
57 56 I56 opi16 OP input 16 CN51 11
58 57 I57 TSW Thread trimming switch input CN39 7
59 58 I58 LSSW Low speed switch input CN39 11
60 59 I59 HSSW High speed switch input CN39 9
61 60 I60 FLSW Presser lifting switch input CN39 5
62 61 I61 SFSW Safety switch CN48 2
63 62 I62 OFSW Optional switch CN48 1
64 63 I63 FLD Knee switch CN36 4
65 64 I64 BTSW Reverse feed stitching switch input CN36 5
66 65 F65 TRMD Thread trimming output CN36 1
67 66 F66 WPD Wiper outut CN36 2
68 67 F67 TLSUBD Thread release output CN36 7
69 68 F68 BTD Reverse feed stitching output CN36 6
70 69 F69 FLD Presser lifting output CN37 1
71 70 F70 S.STATE Output of stop state — —
72 71 F71 UDET Up position input CN33 6
73 72 F72 DDET Down position output CN33 1
74 73 F73 TRMM In the process of thread trimming ——In the process of thread trimming
75 74 F74 DDET_O Down position output — — For direct motor type machine head
76 75 F75 UDET_ O Up position output — — For direct motor type machine head
– 46 –– 58 –
(5) List of simplified program information input setting codes and connector location list
The following list shows port input codes indicated on the 7-segment LED at input, connector numbers on the
substrate, pin assignment, functions, etc.
Input list
Output list
Connector
number and pin
number on substrate
Port input
code
Terminal
names used
in SQ Editor
The operations of No. 75 and 76 are the function in which an up/down detection signal of the direct motor can be used as a signal in a program.
The operations of No. 2 to 33 are the function in which an output can be internally used as an input signal and also as a signal in a program when
an optional output written in a function is used.
Connector number
and pin number on
substrate
Port input
code
Terminal
names used
in SQ Editor
