– 59 –
(6)
Optional power supply
The following list shows the output pin assignment of optional connector power supply voltage.
1.
List of input/output connector voltage output ports
Connector No.
Pin No.
Function
CN44
1
+5V
2
+5V
3
+12V
12
GND
CN51
1
GND
2
GND
12
+24V
13
+24V
14
+5V
CN58
1
+5V
2
GND
3
+5V
4
GND
5
+5V
6
GND
7
+12V
8
GND
9
+24V
10
GND
11
+24V
12
GND
CN59
1
+24V
2
+24V
3
+24V
4
+24V
5
+24V
6
+24V
7
+24V
8
+24V
9
+24V
10
+24V
62
64
