– 41 –
jj
jj
j
Simplified program setting (Function setting No. 142)
Operations of simplified programs are enabled or disabled, and settings of simplified program entry, simplified
program change, and other operations are performed.
Refer to “11. How to use simplified program function (2)” for further information on settings.
kk
kk
k
Brake angle when the needle stops at the up position at thread trimming (Function setting No. 143)
The brake start angle when the needle stops at the up position at thread trimming is specified.
0 to 10 degrees (0: angle of starting to detect up position)
ll
ll
l
Setting of automatic cancellation of alternate vertical output by stitching count (Function setting No. 144)
The alternate vertical output is automatically canceled in accordance with stitching count. (0: automatic cancel-
lation disabled) The alternate vertical output is set to OFF when the predetermined stitching count ends. If “0” is
selected, this function is disabled. (However, the stitching count may exceed the predetermined count depend-
ing on sewing speed.)
0 : Automatic cancellation disabled
1 to 30 stitche
;;
;;
;
Alternate vertical output delay time (Function setting No. 145)
The delay time from when the alternate vertical change switch is pressed to when an output starts to be provided
is specified.
0 to 500 (ms)
zz
zz
z
Selection of alternate vertical output after thread trimming (Function setting No. 146)
The alternate vertical output is forcibly set to ON or OFF after thread trimming.
If this function is disabled, the alternate vertical output stays in the state before thread trimming.
If “1” is selected, the alternate vertical output is set to OFF. If “2” is selected, the alternate vertical output is set to ON.
0 : Disabled
1 : OFF
2 : ON
xx
xx
x
Selection of alternate vertical initial output (Function setting No. 147)
The alternate vertical output at power on is forcibly set to ON or OFF.
If this function is disabled, the alternate vertical output resumes the state when the power was turned off the last
time.
If “1” is selected, the alternate vertical output is set to OFF. If “2” is selected, the alternate vertical output is set to ON.
0 : Disabled
1 : OFF
2 : ON
cc
cc
c
2-pitch output during reverse feed stitching at sewing start and end (Function setting No. 148)
The 2-pitch output is set to ON during control of reverse feed stitching at sewing start and end.
0 : Function OFF
1 : Function ON
vv
vv
v
2-pitch output inversion during alternate vertical output (Function setting No. 149)
The inverted 2-pitch output is provided in synchronism with the alternate vertical output.
When the 2-pitch output is set to “ON” or “OFF” at switching of the alternate vertical output, the output is switched
to “OFF” or “ON”, respectively.
0 : Function OFF
1 : Function ON
bb
bb
b
Selection of 2-pitch initial output (Function setting No. 150)
The 2-pitch output at power on is forcibly set to ON or OFF.
If this function is disabled, the 2-pitch output resumes the state when the power was turned off the last time.
When “1” or “2” is selected, the 2-pitch output is set to “OFF” or “ON”, respectively.
0 : Disabled
1 : OFF
2 : ON
