Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: Channel function "1-byte value transmitter"
Object
h
137
Function
1-byte value transm.
feedback
Name
D.Output
Channel 1
1
Type
1 byte
DPT
5.001,
5.010
Flag
C, W, T,
(R)
2
Description 1-byte object for receiving brightness value feedbacks that an activated
actuator transmits, for example. The status value, status icon and bar graph
for the value visualization are influenced as a result. The feedback of the value
must be transmitted by the "actively transmitting" actuator.
If the activated bus device does not have a feedback function, this object can
be linked with the object "D.Output channel x - 1-byte value transmitter" via an
identical group address.
Function: Channel function "2-byte value transmitter"
Object
h
135
Function
2-byte value transmitter
Name
D.Output
Channel 1
1
Type
2 byte
DPT
9.0xx
Flag
C, -, T, (R)
2
Description 2 byte object to transmit value telegrams. This can cause, for example, a
temperature object, brightness value object or an object with similar
functionality in compliance with KNX DPT 9.0xx to be activated.
Function: Channel function "2-byte value transmitter"
Object
h
137
Function
2-byte value transm.
feedback
Name
D.Output
Channel 1
1
Type
2 byte
DPT
9.0xx
Flag
C, W, T,
(R)
2
Description 2-byte object for receiving brightness value feedbacks that an activated
actuator transmits, for example. The status value, status icon and bar graph
for the value visualization are influenced as a result. The feedback of the value
must be transmitted by the "actively transmitting" actuator.
If the activated bus device does not have a feedback function, this object can
be linked with the object "D.Output channel x - 2-byte value transmitter" via an
identical group address.
Function: Channel function "ASCII Text"
Object
h
137
Function
ASCII text 1
Name
D.Input
Channel 1
1
Type
14
byte
DPT
16.000
Flag
C, W, T,
(R)
2
Description 14-byte object, which can receive ASCII character chains of maximum 14
characters to show a running text on the display.
1: The objects have been described for channel 1 as an example. The objects for the other
channels are defined in the same way by shifting the object number and changing the object
name.
2: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
Page 55 of 347
Software "Smart Control 501511"
Object table
