Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: Weather station display
Object
h
230
Function
Visual. Brightness sensor 2
Name
W.Brightness
sensor 2
Type
2 byte
DPT
9.004
Flag
C, W, -, (R)
1
Description 2-byte object to receive a value telegram for any brightness value (e.g. "Sun
South" of a KNX weather station). The measured value must be made
available to the device via the bus in the format "lux" in compliance with KNX
DPT 9.004. The brightness measured value must be transmitted to the device
via the bus in the format "lux" in compliance with KNX DPT 9.004. The
measured value is converted by the device so that it is displayed in "kLux".
Function: Weather station display
Object
h
231
Function
Visual. Brightness sensor 3
Name
W.Brightness
sensor 3
Type
2 byte
DPT
9.004
Flag
C, W, -, (R)
1
Description 2-byte object to receive a value telegram for any brightness value (e.g. "Sun
West" of a KNX weather station). The measured value must be made
available to the device via the bus in the format "lux" in compliance with KNX
DPT 9.004. The brightness measured value must be transmitted to the device
via the bus in the format "lux" in compliance with KNX DPT 9.004. The
measured value is converted by the device so that it is displayed in "kLux".
Function: Weather station display
Object
h
232
Function
Visual. Max. brightness
Name
W.Max. brightness
Type
2 byte
DPT
9.004
Flag
C, W, -, (R)
1
Description 2-byte object to receive a value telegram for any brightness value (e.g.
"Maximum brightness" of a KNX weather station). The measured value must
be made available to the device via the bus in the format "lux" in compliance
with KNX DPT 9.004. The brightness measured value must be transmitted to
the device via the bus in the format "lux" in compliance with KNX DPT 9.004.
The measured value is converted by the device so that it is displayed in
"kLux".
Function: Weather station display
Object
h
233
Function
Visual. Twilight
Name
W.Twilight
Type
2 byte
DPT
9.004
Flag
C, W, -, (R)
1
Description 2-byte object to receive a value telegram for a twilight measured value of a
KNX weather station. The measured value must be made available to the
device via the bus in the format "lux" in compliance with KNX DPT 9.004. The
display is in the same format.
1: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 57 of 347
Software "Smart Control 501511"
Object table
