Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: Weather station display
Object
h
234
Function
Azimuth visualisation
Name
W.Azimuth
Type
1 byte
DPT
5.003
Flag
C, W, -, (R)
1
Description 1-byte object to receive a value telegram for the current sun status (azimuth
angle). The measured value must be made available to the device via the bus
in the format "°" (0...360) in compliance with KNX DPT 5.003. The display is in
the same format.
Function: Weather station display
Object
h
235
Function
Elevation visualization
Name
W.Elevation
Type
1 byte
DPT
5.003
Flag
C, W, -, (R)
1
Description 1-byte object to receive a value telegram for the current sun status (elevation
angle). The measured value must be made available to the device via the bus
in the format "°" (0...360) in compliance with KNX DPT 5.003. The display is in
the same format.
Function: Weather station display
Object
h
236
Function
Outdoor temp. visualization
Name
W.Outdoor
temperature
Type
2 byte
DPT
9.001
Flag
C, W, -, (R)
1
Description 2-byte object to receive a value telegram for the outdoor temperature of a KNX
weather station. The measured value must be made available to the device
via the bus in the format "°C" in compliance with KNX DPT 9.001. According to
the parameter setting of the measured value, a conversion and display in the
formats "°C" or "°F" takes place if necessary.
Function: Weather station display
Object
h
237
Function
Visualization
external value 1
Name
W.External value 1
Type
2 byte
DPT
9.xxx
Flag
C, W, -, (R)
1
Description 2-byte object to receive and display any value telegram in compliance with
KNX DPT 9.xxx. The display format of the external value can be adapted by
gain, offset, and by the number of places before and after the decimal point.
Function: Weather station display
Object
h
238
Function
Visualization
external value 2
Name
W.External value 2
Type
2 byte
DPT
9.xxx
Flag
C, W, -, (R)
1
Description 2-byte object to receive and display any value telegram in compliance with
KNX DPT 9.xxx. The display format of the external value can be adapted by
gain, offset, and by the number of places before and after the decimal point.
1: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 58 of 347
Software "Smart Control 501511"
Object table
