Art. No. SC 1000 KNX
Function: Weather station display
Object
h
239
Function
Visualization
external value 3
Name
W.External value 3
Type
2 byte
DPT
9.xxx
Flag
C, W, -, (R)
1
Description 2-byte object to receive and display any value telegram in compliance with
KNX DPT 9.xxx. The display format of the external value can be adapted by
gain, offset, and by the number of places before and after the decimal point.
Function: Weather station display
Object
h
240
Function
Visualization
external value 4
Name
W.External value 4
Type
2 byte
DPT
9.xxx
Flag
C, W, -, (R)
1
Description 2-byte object to receive and display any value telegram in compliance with
KNX DPT 9.xxx. The display format of the external value can be adapted by
gain, offset, and by the number of places before and after the decimal point.
Function: Limiting value monitoring for weather station display
Object
h
241
Function
Limiting value
Wind speed
Name
W.Lim. value wind
speed
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
1
Description 1-bit object to receive a limiting value telegram for the wind speed.
"0" = limiting value inactive, "1" = limiting value active
Function: Limiting value monitoring for weather station display
Object
h
242
Function
Limiting value
Brightness sensor 1
Name
W.Lim. value
brightness sensor
1
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
1
Description 1-bit object to receive a limiting value telegram for the first brightness value.
"0" = limiting value inactive, "1" = limiting value active
Function: Limiting value monitoring for weather station display
Object
h
243
Function
Limiting value
Brightness sensor 2
Name
W.Lim. value
brightness sensor
2
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
1
Description 1-bit object to receive a limiting value telegram for the second brightness
value.
"0" = limiting value inactive, "1" = limiting value active
1: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 59 of 347
Software "Smart Control 501511"
Object table
