Table 26: Cable Pinouts for 12-Fiber Ribbon Breakout Cables (Connued)
MPO Connector Pin LC Duplex Connector Pin
12 Rx on LC Duplex 1
12-Ribbon Patch and Breakout Cables Available from Juniper Networks
Juniper Networks sells 12-ribbon patch and breakout cables with MPO connectors that meet the
requirements described earlier. You are not required to purchase cables from Juniper Networks. Table 27
on page 60 describes the available cables.
Table 27: 12-Ribbon Patch and Breakout Cables Available from Juniper Networks
Cable Type Connector Type Fiber Type Cable Length Juniper Model
Number
12-ribbon patch Socket MPO/PC to socket MPO/PC,
key up to key up
MMF
(OM3)
1 m MTP12-FF-M1M
3 m MTP12-FF-M3M
5 m MTP12-FF-M5M
10 m MTP12-FF-M10M
Socket MPO/APC to socket MPO/
APC, key up to key up
SMF 1 m MTP12-FF-S1M
3 m MTP12-FF-S3M
5 m MTP12-FF-S5M
10 m MTP12-FF-S10M
12-ribbon
breakout
Socket MPO/PC, key up, to four
LC/UPC duplex
MMF
(OM3)
1 m MTP-4LC-M1M
