Table 27: 12-Ribbon Patch and Breakout Cables Available from Juniper Networks (Connued)
Cable Type Connector Type Fiber Type Cable Length Juniper Model
Number
3 m MTP-4LC-M3M
5 m MTP-4LC-M5M
10 m MTP-4LC-M10M
Socket MPO/APC, key up, to four
LC/UPC duplex
SMF 1 m MTP-4LC-S1M
3 m MTP-4LC-S3M
5 m MTP-4LC-S5M
10 m MTP-4LC-S10M
24-Fiber MPO Connectors
You can use patch cables with 24-ber MPO connectors to connect two supported transceivers of the
same type—for example, 2x100GE-SR-to-2x100GE-SR.
Figure 23 on page 61 shows the 24-ber MPO opcal lane assignments.
Figure 23: 24-Fiber MPO Opcal Lane Assignments
61
