Configuring IP Forwarding for CTP Bundles (CTPView)
There are two ways to set up CTP bundles for IP forwarding:
•
Direct drive—Packets are forwarded directly between drivers on the local and remote
CTP device. Use this method for simple port-to-port configurations. We recommend
that you use this method with supervision from JTAC.
•
Direct drive disabled—Packets are forwarded based on information in the kernel’s IP
stack.
Before you begin:
•
Log in to the CTPView software at least at the Net_Admin level.
•
Connect the CTPView server to the CTP device for which you want to configure bundles.
To configure IP forwarding for CTP bundles using CTPView:
1. In the side pane, select Bundle > Configuration.
2. Run your mouse over the Display and Select an Existing Bundle bar.
3. In the table of bundles, select the bundle that you want to modify.
4. Under Bundle Options, select Advanced Options Show to display advanced
parameters and configure the parameters as described in Table 17 on page 42.
5. Click Click to Submit Bundle AND Port Changes.
41Copyright © 2018, Juniper Networks, Inc.
Chapter 2: Configuring CTP Bundles
