Configuring the Low-Speed CTP Bundle for TDM/TDC Operation (CTP Menu)
Configure the low-speed bundle on an odd-numbered port that is one higher than the
corresponding high-speed bundle.
Before you begin:
•
Disable the bundle before you modify the bundle options.
To configure the low-speed CTP bundle using CTP Menu:
1. From the CTP Main Menu, select 1) Bundle Operations.
2. Select 1) CTP.
3. Select a bundle from the list. The bundle must be configured on an even-numbered
port.
If you select an active bundle, you are prompted to disable the bundle before
configuring it.
4. Select 3) Port Config.
5. Select 3) Clock Config.
6. Select 1) Port Clock Config.
7. Select 8) TDM/TDC - Interleaved Slow Port.
NOTE: Do not configure any other bundle parameters.
Related
Documentation
TDM/TDC Encoding Overview on page 17•
Configuring T1 and E1 Port Parameters for CTP Bundles (CTPView)
This topic describes how to configure port parameters for T1/E1 interfaces.
Before you begin:
•
Log in to the CTPView software at least at the Net_Admin level.
•
Connect the CTPView server to the CTP device for which you want to configure bundles.
Copyright © 2018, Juniper Networks, Inc.66
Using Bundles to Create Logical Configurations for Physical Interfaces, CTP Release 7.3, CTPView Release 7.3
