Configuring Transparent Encoding for CTP Bundles (CTPView)
This topic describes how to configure transparent encoding for CTP bundles. You must
configure transparent encoding on each end of the circuit.
To reduce transport latency, we recommend that you use the smallest buffer values
possible for networks.
There are two modes of transparent encoding. They are Transparent 4 mode (TRANS)
and Transparent 8 mode (TRANS8). TRANS8 mode is supported only on CTPOS Release
6.4 and later. It is not supported on CTPView. After you configure TRANS8 from CTPOS,
you cannot reconfigure the bundle from CTPView.
This topic describes how to configure the TRANS encoding.
Before you begin:
•
Log in to the CTPView software at least at the Net_Admin level.
•
Connect the CTPView server to the CTP device for which you want to configure bundles.
To configure transparent encoding parameters for CTP bundles using CTPView:
1. In the side pane, select Bundle > Configuration.
2. Run your mouse over the Display and Select an Existing Bundle bar.
3. In the table of bundles, select the bundle that you want to modify.
4. Under Port Options, set Serial Encoding to TRANS.
5. Configure the Port Speed and Clock Cfg as described in Table 23 on page 58.
6. Under Port Options, select Advanced Options Show to display advanced parameters
and configure the parameters as described in Table 23 on page 58.
7. Click Click to Submit Bundle AND Port Changes.
Table 23: CTP Bundle Transparent Encoding Parameter Settings in CTPView
Your ActionFunctionField
Enter a number from 0.00100 through
12880.00000 KHz.
Specifies the sample rate for user data.
The port rate should be a multiple of the
user data rate.
Port Speed
Copyright © 2018, Juniper Networks, Inc.58
Using Bundles to Create Logical Configurations for Physical Interfaces, CTP Release 7.3, CTPView Release 7.3
