Configuring NetRef Multiple Master Nodes (CTP Menu)

NetRef primary backup operation involves a new packet flow from the primary node to

all the backup nodes. These timing packets are sent at a rate of approximately 4.5 packets

per second.

NOTE: In this topic, the terms Primary and Backup refer to master and slave

operations or nodes, respectively.

To configure network node reference with multiple master nodes:

1. From the Main Menu, select 2) Node Synchronization

2. Select 6) NetRef to configure NetRef configuration parameters.

NOTE: You can select 1) 1st Priority, Reference 0, 2) 2nd Priority, Reference

1, 3) 3rd Priority, Reference 2, 4) 4th Priority, Reference 3, and 5) 5th

Priority, Reference to specify the prioritized node clock references. An

external reference input and any of the serial interfaces may be used for

the node reference clock. Reference frequencies must be 32 KHz, n x 64

KHz, or 1,544 KHz up to a maximum of 4096 KHz (2048 KHz maximum

on the CTP1002).

3. From the NetRef Menu, 1) NetRef to enable NetRef on the CTP device..

Enable NetRef (0=Off, 1=Master, 2=Slave, 3=Adaptive Bundle)? (0-3)[2]:

4. Enter 2 to select Slave mode.

5. From the NetRef Menu, select 2) NetRef Master IP (Priority 1). and specify the IP

address of the NetRef master node, which is assigned a priority of 1.

6. From the NetRef Menu, select 3) NetRef Master IP (Priority 1). and specify the IP

address of the NetRef master node, which is assigned a priority of 2.

7. From the NetRef Menu, select 4) NetRef Master IP (Priority 1). and specify the IP

address of the NetRef master node, which is assigned a priority of 3.

8. From the NetRef Menu, select 5) NetRef Master IP (Priority 1). and specify the IP

address of the NetRef master node, which is assigned a priority of 4.

Please select a number from the following list:

-------------------------------------

0) Exit to Shell
