28
8. Three AA batteries should already be installed in the battery holder (C).
Insert the battery holder into the outside housing and secure it using the
supplied 6-32 x 5/16" (7.9mm) Phillips screw (H).
Note: If the lock makes a continuous buzzing noise or the red LED lights
continuously, reset the electronics by removing the battery holder for ten
seconds then reinsert it.
B-6. Reversing the Outside Lever
(for Series without Mechanical Override)
The lever is field reversible. If the handing is incorrect, insert a small pick or
flat screwdriver in the hole in the hub as shown. Gently pry back the spring clip
inside the hub, and remove the handle.
Access Hole
cut-away view
To Next Page
