Kaco blueplanet 10.0 NX3 M2 Quick Guide

KACO blueplanet 3.0 NX3 M2 KACO blueplanet 5.0 NX3 M2 KACO blueplanet 8.0 NX3 M2 KACO blueplanet 10.0 NX3 M2
KACO blueplanet 15.0 NX3 M2 KACO blueplanet 20.0 NX3 M2 260 p.

 
1  
2  pav. ir 8.2 pav., 1 poz.) ir patikrinkite ar tvirtai laikosi.
3   pav., 2 poz.).
[ P / 2 Nm]
» Prietaisas sumontuotas. Toliau atlikite elektros instaliavimo darbus.
6 pav. 
7 pav. Patikrinkite, ar prietaisas patikimai laikosi
8.1 pav.  8.2 pav. 
1.6 Elektros tiekimo prijungimas
NUORODA
pagrindinius



1.6.1 Bendras inverterio vaizdas iš apačios
8.2 pav. Prijungimo pusė. Eksplikacija
A 
D
COM3 – Wi-Fi modulio jungtis
B -generatoriui
E

C COM1&2 – RJ45 lizdas RS485 prijungimui
F


Kaco blueplanet 10.0 NX3 M2 Specifications

General

Model	blueplanet 10.0 NX3 M2
Manufacturer	Kaco
Category	Inverter
Max. AC Output Power	10000 W
Max. DC Voltage	1100 V
Number of MPPTs	2
Max. apparent AC power	10000 VA
AC frequency	50 Hz / 60 Hz
Max. AC current	16 A
Max. DC current	26 A
Protection class	IP65
Topology	Transformerless
Operating Temperature Range	-25°C to +60°C
Cooling	Convection
Max. DC power	15000 W
AC Output Voltage	230 V / 400 V
AC voltage range	230 V / 400 V
