TECHNICAL DESCRIPTION ULTRAFLOW
®
54 and 34
5512-385 GB/02.2014/Rev. H1
18
ULTRAFLOW
®
, DN20 to DN50
Figure 3
Flange EN 1092, PN25. Flange facing type B, raised face
Nom. Bolts
Approx.
weight
diameter L M H2 B1 D H k Number
Thread
d
2
[
[[
[kg]
]]
]
DN20 190
L/2 89 58 105
95 75 4 M12 14 2.9
DN25 260
L/2 89 58 115
106
85 4 M12 14 5.0
DN40 250
L/2 89
<D/2
150
136
110
4 M16 18 7.9
DN40 300
L/2 89
<D/2
150
136
110
4 M16 18 8.3
DN50 250
155
89
<D/2
165
145
125
4 M16 18 9.8
DN50 270
155
89
<D/2
165
145
125
4 M16 18 10.1
Table 13
