J26: (internal regulator output voltage select) Not installed. For future devel
-
opment. When installed, this jumper is to be used with R122 to program a supply
voltage of less than +5V.
Appendix C: Options for the KAM’98
Installing Additional RAM
The KAM’98 is shipped with 128K bytes of RAM. It is possible to expand the
RAM in the KAM’98 up to a maximum of 512K bytes.
Expanding the RAM to 512K bytes requires that you:
• remove the existing 128K RAM in socket U15, then
• install a 512K low-power static RAM in U15.
Replacing the Lithium Battery
To replace the internal Lithium battery, remove the cover from your KAM’98 and
carefully slip the battery out of the battery holder. You may need to use an insu
-
lated tool to assist in removal of the battery. When installing a replacement bat
-
tery (CR 2032 or equivalent), be sure you have the positive terminal against the
top clip of the battery holder.
NOTE: When you remove the lithium battery from your KAM’98, all stored pa
-
rameters will be lost and the unit will revert to the factory default parameters.
Appendix C: Options for the KAM’98 Appendix B: Advanced Information
KAM’98 v 8.3 345 User’s Guide
